We offer: a shirring machine ”Eichel R 1000”
• Two-tube shirring machine suitable for all types of casing
• Fully automatic for bead lenghts of up to 500 mm
• Shirring head for spiral shirring system with two separately adjustable drives for casing calibre 38–90 mm or for casing calibre 90–140 mm
• Carriage drive via ball threaded spindle with servo motor
• Sturdy welded frame construction with processed machine bed
• Top cover with sliding doors made of aluminium profiles with Macrolon panes for noise reduction. Frame covers made of synthetic material
• Unwinder with pneumatic tension core 76 mm and pneumatic dancer with magnetic particle brake for adjusting the tension
• All drives are sensitively adjustable via servo and frequency controllers
• Calibre range: 38 to 140 mm
• Capacity: approx. 4 beads/minute at 20 m length, approx. 3.5 beads/minute at 30 m length
• Main voltage: 400 Volt, 50 Hz, 15 kW
• Compressed air: 6 bar, approx. 400 l/minute
• Dimensions: 7.5 x 2.5 x 2.0 m
• Weight: approx. 5,300 kg
• Year of manufacture: 1996
The machine is still on the former production site and can be demonstrated any time.
Please send all inquiries to: info@ft-systeme.de
|
